EAC Zertifizierung von industriellen Rohrleitungsarmaturen

The conformity assessment of the industrial pipeline valves and fittings like butterfly valves, gate valves, shut-off valves proves the safety of the product and its compliance with the technical regulation of the Eurasian Economic Union .

After successful conformity assessment the manufacturer obtains a certificate of conformity.

Conformity assessment according to TR CU 032/2013 On safety of pressure equipment

Some pipeline valves fall under the regulation of the TR CU 032/2013 On safety of pressure equipment.

Pipeline valves for Group 1 (Working Medium Gas/Steam)
Nominal diameter (mm) Maximum allowable working pressure (MPa) Product des maximal zulässigen Arbeitsdruckwerts mit dem Nenndurchmesser (MPa · mm) Prove of Conformity
over 25 and up to and including 100 over 0,05 and up to and including 3,5 up to and including 100 EAC Declaration
over 25 and up to and including 100 over 3,5 over 100 EAC Declaration
over 25 and up to and including 350 over 1 and up to and including 3,5 over 100 and up to and including 350 EAC Declaration
over 100 and up to and including 350 over 1 and up to and including 3,5 over 350 EAC Certificate
over 100 over 3,5 not regulated EAC Certificate
over 350 over 0,05 and up to and including 3,5 not regulated EAC Certificate
Pipeline Valve for Gruppe 2 (Working Medium Gas/Steam)
Nominal diameter (mm) Maximum allowable working pressure (MPa) Produсt of maximum allowable working pressure and Nominal diameter (MPa · mm) Prove of Conformity
over 32 and up to and including 100 over 0,05 and up to and including 3,2 and more over 100 and up to 350 and more EAC Declaration
over 100 and up to and including 250 over 0,05 and up to and including 3,2 and more over 350 and up to and including 500 and more EAC Declaration
over 250 over 0,05 and up to and including 3,2 over 500 EAC Certificate
Pipeline valve for Group 1 (Working medium Liquid)
Nominal diameter (mm) Maximum allowable working pressure (MPa) Produсt of maximum allowable working pressure and Nominal diameter (MPa · mm) Prove of Conformity
over 25 over 0,05 and up to and including 3,2 and more over 200 EAC Deklaration
over 25 over 8 and up to and including 50 over 500 EAC Declaration
Pipeline Valve Group 2 (Working medium Liquid)
Nominal diameter (mm) Maximum allowable working pressure (MPa) Produсt of maximum allowable working pressure and Nominal diameter (MPa · mm) Prove of Conformity
over 200 over 1 and up to and including 50 and more over 500 EAC Declaration

With our Pressure equipment category calculator you can determine which category your equipment belongs to:

Conformity assessment according to TR CU 010/2011 On safety of machinery and equipment

Following fittings underly an obligatory conformity assessment according to TR CU 010/2011 On safety of machinery and equipment in form of EAC Declaration:

  • isolation valve
  • control valve
  • safety valve
  • gate valve
  • ball valve
  • filter

Conformity assessment procedure

For EAC Declaration of the pipeline valves the following conformity assessment procedures come into consideration:

Procedure Description
1D EAC Declaration for serial delivery
2D EAC Declaration for series production
3D EAC Declaration for serial delivery
4D EAC Declaration for single-unit products or small series production
5D EAC Declaration for products used in manufacturing facilities with enhanced hazard or for innovative Products for which no Standards have been developed
6D EAC Declaration for serial production, if there is a certificate of quality management

After successful conformity assessment, EAC Declaration can be issued and subsequently registered at the Central Registry of the EAEU.

Tests conduction

Conduction of tests is stipulated in the technical regulation.
At the first stage the product underlies a visual control and measurement.
Afterwards, the main characteristics of the product must be examined:

  1. Conduction of pressure tests. The product is tested on material density, material's strength etc.
  2. In addition, special pressure characteristics will be checked to ensure the safety and reliability of the products
  3. Finally, the material’s strength is tested under the influence of technical, climatic, and thermal forces

The tests are conducted in the notified laboratories

Common requirements for industrial pipeline valves

In order to carry out the test successfully, the following characteristics of the product must be observed:

  • safety (service life, storage etc)
  • reliability (maintainability, operative life, fail-safe operation, resistance)
  • function (operating mode, diameter, pressure, hydraulics)
  • constructional features (transportability, processing, assembly capabilities)
  • environmental friendliness
  • strength (technical endurance, elastic deformation, thermal expansion, pressure resistance)

Special regulation for valves used in manufacturing facilities with enhanced hazard

The usage of the valves in manufacturing facilities with enhanced hazard is defined in the Federal Law from 21.07.1999 N 116-FZ „About industrial security in manufacturing facilities with enhanced hazard“.

In this case a survey report about the safety is needed.

Authorized representative

Bevollmächtigter VertreterThe manufacturer, which is not established in one of the Member States of the Eurasian Economic Union, is not entitled to apply for any EAC conformity certificate.

In accordance with applicable law and in accordance with the technical regulations of the Eurasian Economic Union, only an entrepreneur residing in the territory of the Customs Union may be designated as an authorized representative.

In order to get the conformity certificate, the foreign manufacturer must appoint an authorized representative in one of the countries of the Eurasian Economic Union. He represents the interests in the certifying bodies of the Eurasian Economic Union regarding the safety and quality of products and compliance with technical regulations. Our company - Schmidt & Schmidt - offers you an authorized representative on the territory of the Eurasian Economic Union.

Our offer

Our export consultants have many years of experience in the import pipeline valves to Russia as well in its certification and customs processing. We offer a comprehensive service package, which includes the preparation of all necessary documents, the corresponding customs handling, and the logistics. We will help you acquire necessary certificates and permits.

We offer:


Please call us or send us an email. We will provide you with a free, non-binding quote and will be glad to answer all your questions about import and certification. Convince yourself of the quality of our services!

In our video, we explain what an EAC Certification is and how and where to certify or declare your products for the introduction on the EAEU market.

The EAC Certification and the EAC Declaration are complex procedures that attest your products the conformity with the technical regulations of the EAEU and require a lot of know-how. Schmidt & Schmidt will support you with the certification of your products for the EAEU market.

The EAC certificate of the Eurasian Economic Union (EAEU) is an official document, that proofs the conformity of the products with the harmonized technical regulations of the member states of the EAEU. The products, whose conformity with the technical regulations could be confirmed by the certificate of the EAEU, may be moved and sold in the whole customs area of the member states of the EAEU.

The EAC Declaration of the Eurasian Economic Union (EAEU) is an official document that proofs, that the products meet the minimum requirements of the technical regulations of the EAEU. An EAC declaration is issued by the manufacturer, importer or an authorized representative and listed in the official register. Those products, whose conformity with the technical regulations are confirmed by the declaration, have the permission to be freely moved and sold in the whole customs territory of the member states of the EAEU.

The EAC certificate can only be issued after a quality assessment, which has to be carried out by a certification body accredited in one of the member states of the Eurasian Economic Union. The certification is conducted on the basis of technical documentations, company-internal created test reports, or rather test reports provided by accredited test laboratories, as well as on basis of a manufacturing audit on site. The certificate is printed on an official pre-printed form, which has several forgery-proof elements and is authenticated by the signature and seal of an accredited body. The EAC certificate is usually issued for “complex” products that require an extensive control by the authorities.

With the EAC Declaration the manufacturer, importer or authorized representative declares the conformity of his products with the minimum requirements of the technical regulation of the Eurasian Economic Union (EAEU). As distinguished from the EAC certificate, the EAC declaration is issued by the manufacturer or importer himself. All necessary tests and analysis are or made by the manufacturer or in some cases by the laboratory. The applicant issues the EAC declaration himself on a usual piece of paper. The EAC declaration has to be listed in the uniform register of the EAEU by an accredited certification body of one of the member states of the EAEU.
